Regen is loaded with content to get you inspired fast. There are over 550 timbre presets across 10 newly-commisioned timbre libraries. On top of that, there are over 2000 royalty-free samples built-in, including over 350 selected original samples from the NED era and 2 exclusive artist sample libraries.

When you’re done exploring the factory content, you’ll have fun with the sound design possibilities. You can layer up to 12 partials with different sound generators (additive, subtractive, samples) then apply dynamic effects per partial. It’s truly an expressive instrument, both to program and to play. Polyphonic aftertouch and MPE is fully-supported and there’s a sophisticated modulators section where you can apply responsive curves to properties driven by pressure, velocity, mod wheel position, and so on.

Features

• 255 Regen timbre presets
• 700+ samples of royalty-free factory content
• Additive waveforms, subtractive waveform generator and multi-sample patchlists
• 12 partials to build your sounds.
• 12 tracks for multi-timbral playback or stacking (layering) of sounds.
• 4 USB ports for keyboards and other peripherals plus one USB port for connection to DAW. And 5-pin MIDI standard (TRS).
• 2 full-colour high resolution screens
• Senstive liquid-like touch swiper and 12 selector pads.
• Multiple effects per track, including chorus, reverb, vibrato, tremolo, arpeggiator, bit crush, and multi-mode filter.
• High fidelity DC-coupled audio out (stereo XLR or TS) with 130dB of dynamic range.

Synclavier Regen Specifications
Form
Synclavier Regen is a desktop unit measuring 310mm wide by 260mm tall and 42mm deep.
Housed in aluminum, finished with a sand-textured black and Synclavier red surround.
It has rubberized plinths.

User interface consists of many silicone buttons with multi-colour backlighting, a virtual knob
capacitive-touch slider with epoxy-coating. A VK display is included as well as a main modal
display that shows current parameters, user settings, timbre library, etc.

Over 40 years of synth design has led to this product. It’s a sound-designer’s dream in a
timeless desktop package.

Sound-design Capabilities
• Advanced DSP synth engine, as used on Synclavier II, has been extended for Regen.
• 12 separate tracks of multi-timbrality, assignable to MIDI tracks and keyboard ranges.
• Up to 98 simultaneous voices. Voice count is dependent on system load and is likely to
be much higher in typical scenarios.
• 12 partials per timbre. Each partial can be 1 of 3 oscillator synth modes: additive,
subtractive, or samples.
    o Additive mode supports coefficient and phase control of 24 harmonics.
    o In samples mode, up to 48 samples can be placed on the partial’s patchlist.
    o Subtractive can have a noise generator or up to 9 de-tunable continuous
sawtooth waveforms.
    o Hybrid (resynthesized samples)
• Timbre-level effects, including:
    o Stereo reverb algorithm with pre-delay and library of presets.
    o Highly-optimised multi-mode filter with sophisticated filter envelope.
    o Bit-crusher (for use with additive modes).
• Frequency modulation (FM) controllable per partial (all modes) with envelope.
• Sophisticated modulation system that allows many Regen parameters to be controlled
via MIDI, LFOs (24 per timbre), or driven by envelopes (24 per timbre).
• Approx 300MB of sample space in memory = 100 mins @ 48Khz 24-bit mono shared
across all active tracks and partials.

Hardware
• Balanced streo output through XLR connections at pro-level 4dBu. Designed for studio
and home use. These are DC-coupled for maximum bass impact.
• Single-ended TS stereo outputs, also DC-coupled.
• Convenient headphones TRS jack for monitoring master audio with independent volume
control. For headphones in range 32W – 300W.
• DAC circuit is designed for ultra-low noise floor. 11dB of headroom over nominal level. A
measured 130dB of dynamic range. 24-bit, 50kHz sample rate, as per Synclavier II.
• Hybrid sound design engine: original Synlcavier II hardware is modelled in software.
• High quality audio components throughout, including a precision temperature-
compensated crystal oscillator for jitter-free digital audio.
• Two glorious full-colour sunken displays.
• Reponsive silicon back-lit parameter buttons.
• The vertical value swiper is touch accurate to 128 levels of resolution for precise control
of every parameter.
• 12 selector buttons are touch-sensitive and can handle gestures to quickly select
multiple partials or tarcks.
• SD Card reader for unlimited user timbre and sample libraries.
• 4 USB accessory ports for MIDI keyboards, sequencers, and audio interfaces. Plus 1 USB
Host port for connecting to a computer for MIDI input from a DAW.
• Take it on the road. Rugged, full metal enclosure. Designed to fit in a back-pack.

Features
• Over 550 preset timbres categorised by instrument and tags. Including 64 of Anthony
Marinelli’s hand-picked timbres from his film composing career (Blue Thunder, War
Games, Heart like a Wheel, Stakeout).
• Over 2000 royalty-free samples, including over 350 selected original NED samples, and
195 commissioned for Regen by sound pioneers, Jamie Lidell and Leith Fleming Smith.
• Polyphonic aftetouch and MPE are supported and many presets are optimised for MPE
expression.
• Built-in help pages, comprehensive operators manual available replete with sound
design tutorials.
