Erica Synths Pico Trigger module provides a master clock for the Pico System and it generates up to 16 step patterns of 4 triggers, simple clock divider patterns, and more advanced polyrhythmic patterns of different step length for triggering drums.
Features
- Selectable internal clock or external clock
- Clock output
- Polyrhytmic patterns
- Adjustable shuffle
- 4 trigger outputs
- 8 pattern memory
- Web-based pattern design interface
- Pattern upload via CLK input
You can design your patterns in a custom web interface and then upload them to the module via CLK in 3,5mm jack.
With Pico Series we challenged ourselves – can we make ANY superior functionality synth module 3HP wide and affordable? Yes, we can.
Technical specification:
| Clock rate | 20BPM – 420BPM |
| Trigger amplitude | 5V |
| Trigger duration | 10ms |
| Power consumption | +20mA, -5mA |
| Module width | 3HP |
| Module depth | 35mm |
