This DIY.EDU Labor add-on, featuring the oscilloscope, the voltmeter, the spectrometer and the tuner, turns the Labor into self-contained electronics development and experimentation station.
Features
- The 3-channel oscilloscope. Two channel inputs are available on female connector, the third channel is hard wired to the audio output of the Labor.
- Lissajous curves visualizer.
- The voltmeter, 10V range, 0.1V accuracy.
- The spectrometer, with configurable representation.
- The chromatic tuner.
NB! The DIY.EDU Labor Scope is intended for use exclusively with the Labor platform, and other applications and modifications may lead to permanent damage of the instrument.
