COMPACT, PERFORMANCE ORIENTED 4 CHANNEL STEREO MIXER WITH SIDECHAIN DUCKING
-
4 channel stereo performance mixer
-
Daltonic friendly - the LEDs are blue/red instead of red/green
-
Channel 1 features a stereo input jack, Channels 2/3/4 are dual mono
-
On-board compressor with external sidechain control voltage option (3 modes) to add dynamics to your mix.
-
Stereo output for speakers or headphones with enough current to drive a wide range of headphones
-
extra aux, stereo out, balanced output pins, compatible with Intellijel Audio Jacks V2 Boards / cases
-
available in 3U / 6HP version
Power consumption:
-
40 mA +12V
-
25 mA -12V
-
0 mA 5V
Dimensions:
-
24 HP (1U)
-
42 mm deep (fits all Intellijel Palette cases etc).
FAQ:
I cannot switch the algorithm of the Sidechain Compressor. Make sure the encoder buttons work properly i.e they mute/unmute each channel. Also make sure you press all 4 encoders at once. Holding for 1 second while they being pressed will switch the mode in which the Cockpit is indicated by blinking of the blue LED. The mode is stored in a few seconds and will load on the next module's power up.
Rainbow cable pinout. Side red/brown pair of pins always correspond to -12V similar as with typical gray ribbon cable.
What cables are supplied with Cockpit 1U module. 10-10 ribbon power cable, 6-6 ribbon cable for balanced output into Intellijel Audio Jacks V2 board. Note: you have to get dupont daily chain (a.k.a. mixup) wires on your own.
