QUADIGY
Quad Envelope Generator
- Quad 7-stage envelopes
- Pre-delay
- Hold
- Attack
- Punch
- Decay
- Sustain
- Release
- Continuous curve shape setting
- Inversion
- Independent output level
- Cycle capability with auto fit-to-clock
- Elastic time stretching
- 5 internal clocks with tap tempo
- External clock control
- Multiply/divide and offset
- Individual cycle ext. control
- 32 presets with naming
- External preset control via CV/Trig
- Simultaneous 156-point CV matrix
- Morphing on presets and CV Matrix
- Multi-editing for polyphonic uses
- Live mode for easier/safer control
- Graphical display
- Real-time envelope stages LED indication
- Current state retained over power cycle
- Easy firmware update via an audio file
- Skiff-friendly and compact module
The Quadigy is a complex envelope generator focused on live play. The goal is to allow the user setting up rich, interactive and dynamically evolving envelopes without the risk of breaking up a subtle and intricate patch once on stage.
This is achieved by offering two main modes, one where full control is available and a Live mode where only the settings that are sensible using on stage are accessible.
Mechanical
| Dimensions | mm | inches | Eurorack |
|---|---|---|---|
| Height | 128.40 | 5.06 | 3HE |
| Width | 71.00 | 2.8 | 14HP |
| Depth behind panel (with supply cable inserted) |
38.00 | 1.49 |
Supply
| Supply rail | Current draw |
|---|---|
| +12V | 24mA |
| -12V | 10mA |
| +5V | 40mA |
