Modor NF-1M - Digital Polyphonic Synthesizer

$659.00
SKU:
ModNF-1m01
Quantity:

Product Description

MODOR NF-1m

The original Modor NF-1, whilst being very hands-on, is quite big and heavy. Not your favourite piece of hand luggage to carry around. So we decided to make a smaller, portable version. And of course, a smaller device means a smaller price...!

This comes of course with a smaller number of frontpanel controls... The Modor NF-1m has 7 context dependant controls grouped in 15 edit pages with a set of 6 pushbuttons to acces these pages quickly. Every parameter is just a button press away!

Next to that, there are 2 large 'defineable controls', DEF1 and DEF2. These controls can be assigned to any sound parameter so that you can 'preselect' two parameters in every patch to have a permanent dedicated control on the frontpanel. This makes it easy to acces your favourite parameters, no matter in which edit page you are...



SPECIFICATIONS

POLYPHONY
  • 8 voices
  • Poly, Mono and Mono-legato modes



MEMORY
  • 448 patches, 14 banks [A-N] of 32 patches
  • All factory presets overwritable



CONNECTIONS
  • 9V, 600mA adapter connection, positive voltage on center pin
  • MIDI IN/THRU/OUT connections, 3x 5-pin DIN connection
  • Audio Left and Right outputs, 6.35mm mono jack
  • Sustain switch, 6.35mm mono jack
  • Volume/modulation pedal, 6.35mm stereo jack
  • MIDI over USB connector



DISPLAY
  • 16x2 green backlit LCD display



FRONT PANEL CONTROLS

  • 8 rotary knobs
  • 8 pushbuttons
  • 1 rotary encoder
  • 1 Power switch/volume knob

MIDI

  • Full realtime MIDI control of all 'continuous' sound parameters
  • Pitch Bend, Velocity, Aftertouch (Channel&Poly), Modwheel (CC#1), BreathCtrl (CC#2), CC#3 and Expression pedal (CC#4) modulation
  • Backups and patch exchanges via Patch, Bank and Memory Sysex Dumps
  • Firmware upgrades via Sysex
  • MIDI MPE-compatible



MEASUREMENTS

  • Width: 248mm
  • Height: 70mm
  • Depth: 120mm
